698849

Carbon nanotube, multi-walled

Name: Carbon nanotube, multi-walled
Brand: ALDRICH

>98% carbon basis, O.D. × L 6-13 nm × 2.5-20 μm

Synonym(s):

MWCNT, MWNT, Multiwall carbon nanotube

Select a Size

Change View

About This Item

CAS Number:

308068-56-6

MDL number:

MFCD00133992

UNSPSC Code:

12352103

NACRES:

NA.23

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

100

assay

>98% carbon basis

form

powder

composition

carbon, >98% (total metals impurities)

O.D. × L

6-13 nm × 2.5-20 μm

size

10 μm , average length, TEM, 12 nm , average diameter, HRTEM

surface area

~220 m²/g , SSA

mp

3652-3697 °C (lit.)

density

~2.1 g/mL at 25 °C (lit.)

SMILES string

[C]

InChI

1S/C

InChI key

OKTJSMMVPCPJKN-UHFFFAOYSA-N

Description

General description

Multi walled carbon nanotubes (MWNTs, CNTs) were prepared by chemical vapor deposition (CVD). In chemical vapor deposition (CVD), a volatile precursor undergoes thermal decomposition at elevated temperatures to form a solid deposit on a substrate. The diameter of the tube ranges between 6-13nm and the average length is 10μm. The multiwalled nanotubes are stable in inert atmosphere upto a temperature of 3697^oC. CVD production method is followed by HCl demineralization.

Application

A hybrid nanostructure system of MWNTs/titania was fabricated to be used as photodiodes in dye sensitized solar cells. MWNTs were investigated as electrodes for electrochemical biosensors. Use of MWNTs increased the efficacy, sensitivity and mechanical strength of the sensors.

Carbon nanotube, multi-walled (MWNT) belongs to the class of carbonaceous materials with excellent physiochemical, thermo-mechanical and electrochemical properties. This material can be used in a variety of sustainable energy applications such as solar cells, photocatalysis, biosensor, gas sensor, supercapacitor and as a filler that acts as a reinforcement to improve the mechanical property of composites.

Physical form

average wall thickness 7-13 graphene layers

Preparation Note

Chemical Vapor Deposition (CVD) Method

Still not finding the right product?

Explore all of our products under Carbon nanotube, multi-walled

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves
