901082

Carbon nanotube sheet

Name: Carbon nanotube sheet
Brand: ALDRICH

aligned, size × thickness 100 mm × 100 mm × 1-5 μm

Synonym(s):

MWCNT, MWNT, Multiwall carbon nanotube

Select a Size

Change View

About This Item

CAS Number:

308068-56-6

MDL number:

MFCD00133992

UNSPSC Code:

12352103

NACRES:

NA.23

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

100

assay

>95% (carbon)

resistivity

10-1000 Ω/sq

size × thickness

100 mm × 100 mm × 1-5 μm

diameter

10-40 nm (carbon nanotubes)

SMILES string

[C]

InChI

1S/C

InChI key

OKTJSMMVPCPJKN-UHFFFAOYSA-N

Description

General description

Multi-walled carbon nanotubes are aligned in a direction. The CNTs are just connected with van der Waals forces, and no binder material is used. The sheet shows high anisotropic transport properties, including electrical conductivity and thermal conductivity.
CNT has a multi-walled structure. Crystal quality of CNT is examined by Raman scattering measurement. Intensity ratio of G-peak (1580 cm^-1) and D-peak (1350 cm^-1) represents quality of graphitization of carbon materials. G/D of CNT is ∼3, showing high crystal quality. The high crystallinity is supported by transmission electron microscopy.

Preparation Note

Chemical Vapor Deposition (CVD) method.

Still not finding the right product?

Explore all of our products under Carbon nanotube sheet

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable
