765155

Lithium titanate

Name: Lithium titanate
Brand: ALDRICH

spinel, electrode sheet, aluminum substrate, size 5 in. × 10 in.

别名:

LTO, Lithium titanate spinel oxide

登录查看组织和合同定价。

选择尺寸

变更视图

关于此项目

线性分子式:

Li₄Ti₅O₁₂

NACRES:

NA.23

PubChem Substance ID:

329767159

UNSPSC Code:

26111700

MDL number:

MFCD11656084

技术服务

需要帮助？我们经验丰富的科学家团队随时乐意为您服务。

让我们为您提供帮助

属性

grade

battery grade

description

Nominal Voltage: 1.5 V, Li/Li+

assay

≥98%

form

sheet

composition

loading, ≥80%

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

extent of labeling

≥80% loading

size

5 in. × 10 in.

thickness

25-50 μm

particle size

1.5-3 μm (typical)

capacity

150 mAh/g(minimum), 160 mAh/g(nominal at 0.1C)

mp

>1000 °C

application(s)

battery manufacturing

greener alternative category

Enabling,

SMILES string

[Li+].[Li+].[Li+].[Li+].[O-][Ti](=O)O[Ti](O[Ti]([O-])=O)(O[Ti]([O-])=O)O[Ti]([O-])=O

InChI

1S/4Li.12O.5Ti/q4*+1;;;;;;;;;4*-1;;;;;

InChI key

BNQVSKURWGZJMY-UHFFFAOYSA-N

说明

General description

Lithium titanate (LTO) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage.

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.

Application

Lithium titanate (LTO) spinel electrode sheet can be used as an anode material, which shows an ion conductivity of 10⁻³ Scm⁻¹ at room temperature. It can also be used as an alternative to conventional graphite materials. It can further be used in the fabrication of high-performance lithium-ion batteries for electric vehicles (EVs).

Other Notes

Crystal Structure: Spinel, cubic, Fd-3m

Operating Condiditons:

Recommended maximum charge voltage: 3.0 V vs Li/Li⁺
Recommended maximum charge current: 5 C
Recommended cut-off voltage for discharge: 1.0 V vs Li/Li⁺
Recommended maximum discharge current: 10 C

Still not finding the right product?

Explore all of our products under

存储类别

11 - Combustible Solids

wgk

WGK 3

历史批次信息供参考:

分析证书(COA)

Lot/Batch Number

MKBZ9816V

MKBM2271V

没有发现合适的版本？

如果您需要特殊版本，可通过批号或批次号查找具体证书。

搜索COA

已有该产品？

在文件库中查找您最近购买产品的文档。

访问文档库

商品

锂离子电池电极材料

固体氧化物燃料电池(SOFC)和固体氧化物电解池(SOE)正处于早期开发阶段，但性能发展已有望实现电化学能量的转化。

Electrode Materials for Li-ion Batteries

Solid oxide fuel cells and electrolyzers show potential for chemical-to-electrical energy conversion, despite early development stages.

Ionic Liquids for Rechargeable Batteries

Ionic liquid electrolytes explored for rechargeable batteries' advancement; future IL development discussed.

查看所有文章

Jansen, A. N.; et al.

Journal of Power Sources, 902, 81-82 (1999)

Wu, H-C.; et al.

Journal of Power Sources, 197, 301-301 (2012)

Ionic conductivity, lithium insertion and extraction of lanthanum lithium titanate

Chen CH and Amine K

Solid State Ionics, 144(1-2), 51-57 (2001)

查看所有相关文献

全球贸易项目编号

货号	GTIN
765155-1EA	04061826751992
