920053
Graphene, monolayer film
large grain, CVD graphene on copper foil, A3 size
别名:
Roll-to-Roll graphene
登录 查看组织和合同定价。
选择尺寸
变更视图
关于此项目
产品名称
R2R Monolayer large grain CVD graphene on copper foil, A3 size, avg. no. of layers, 1
Quality Level
description
Growth method: roll-to-roll CVD
Number of layer: Monolayer
Raman intensity 2D/G: ≥1.5
feature
avg. no. of layers 1
sheet resistance
280 Ω/sq ±10%
size
110 μm × 110 μm ± 10% , grain size
thickness
35 μm , Cu Foil
surface coverage
surface coverage >98%
transmittance
>97%
semiconductor properties
(mobility>3000 cm2/V·s) (Hall effect measurements)
SMILES string
NC.NC.NC.NC.NC.NC.NC.NC.NC
InChI
1S/9CH5N/c9*1-2/h9*2H2,1H3
InChI key
DXIFQVRACSPGSU-UHFFFAOYSA-N
General description
Roll-to-roll, high-quality, monolayer CVD graphene with large grain size (∼110μm2) on copper foil, A3 size.
Application
Our Roll-to-Roll CVD graphene products are true monolayer high quality graphene, fabricated inside a Cleanroom, heavily monitored and QC to assure high reproducibility.
The roll-to-roll process allows continuous, large scale graphene production.
This large grain size product with low sheet resistance would enable unmatched reproducibility and allow high performance for CVD graphene based FET, CVD graphene based sensors, and heterostructure based micro/nano electronics.
Application examples:
The roll-to-roll process allows continuous, large scale graphene production.
This large grain size product with low sheet resistance would enable unmatched reproducibility and allow high performance for CVD graphene based FET, CVD graphene based sensors, and heterostructure based micro/nano electronics.
Application examples:
- Ultrafast Transistor
- Optical devices
- Bio/Gas Sensor
- Transparent Electrode
- Flexible Display
- Smart Coating
- Thermal management
Preparation Note
Avoid direct sun light, avoid high temperature, avoid high humidity, and avoid dust.
Be cautious not to drop
Keep away from contamination, heat, dust and flame etc.
Keep away from contamination, heat, dust and flame etc.
Legal Information
Product of LG Electronics, R&D use only
signalword
Warning
hcodes
pcodes
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 1
存储类别
13 - Non Combustible Solids
flash_point_f
Not applicable
flash_point_c
Not applicable
法规信息
新产品
此项目有
商品
Review on 1D vdWHs: Discusses materials, synthesis, optoelectronic applications, challenges, and future perspectives for 1D vdWH-based devices.
Integrating graphene into semiconductor fabrication lines.
Daniel Neumaier et al.
Nature materials, 18(6), 525-529 (2019-05-23)
Bing Deng et al.
Advanced materials (Deerfield Beach, Fla.), 31(9), e1800996-e1800996 (2018-10-03)
Chemical vapor deposition (CVD) is considered to be an efficient method for fabricating large-area and high-quality graphene films due to its excellent controllability and scalability. Great efforts have been made to control the growth of graphene to achieve large domain
全球贸易项目编号
| 货号 | GTIN |
|---|---|
| 920053-1EA | 04065265670029 |
