59247-U
SUPELCOGEL™ 8Ca (9 µm) HPLC Columns
L × I.D. 30 cm × 7.8 mm
别名:
SUPELCOGEL™ 8% Crosslinked HPLC Column
登录 查看组织和合同定价。
选择尺寸
变更视图
关于此项目
UNSPSC Code:
41115700
NACRES:
SB.52
L × i.d.:
30 cm × 7.8 mm
Particle size:
9 μm
Matrix:
sulfonated polystyrene/divinylbenzene, spherical, polymeric
产品名称
SUPELCOGEL™ 8Ca, 8% Crosslinked HPLC Column, 9 μm particle size, L × I.D. 30 cm × 7.8 mm
material
stainless steel column
Quality Level
agency
suitable for USP L19
product line
SUPELCOGEL™
feature
endcapped: no
manufacturer/tradename
SUPELCOGEL™
packaging
1 ea of
parameter
400 bar pressure (5801 psi), 85 °C max. temp.
technique(s)
HPLC: suitable
L × I.D.
30 cm × 7.8 mm
matrix
sulfonated polystyrene/divinylbenzene, spherical, polymeric
particle size
9 μm
separation technique
ligand exchange
General description
SUPELCOGEL 8 Column Series (manufactured with 8% XL PS-DVB):
The majority of columns on the market for the analysis of carbohydrates, organic acids, and alcohols, such as Aminex®, utilize an 8% XL PS-DVB. The 8% polymer offers excellent separation of many common samples.
Advantages: 8% polymers combine durability and good resolution. Due to higher cross-linking than 6% XL polymers, columns packed with 8% polymer can be used at higher flow rates therefore decreasing analysis times.
Disadvantages: 8% polymers are limited in separating carbohydrates larger than trisaccharides due to lower MW exclusion limits. Compared to the 6% XL polymer, for some types of carbohydrate and organic acid mixtures, the 8% shows less resolution due to selectivity differences.
Molecular Weight Exclusion Limit: 1200
Minimum Wet Capacity meq/ml: 1.7 - 1.9
Flow Rate Recommendation: 0.4 - 1.2 ml/min
The majority of columns on the market for the analysis of carbohydrates, organic acids, and alcohols, such as Aminex®, utilize an 8% XL PS-DVB. The 8% polymer offers excellent separation of many common samples.
Advantages: 8% polymers combine durability and good resolution. Due to higher cross-linking than 6% XL polymers, columns packed with 8% polymer can be used at higher flow rates therefore decreasing analysis times.
Disadvantages: 8% polymers are limited in separating carbohydrates larger than trisaccharides due to lower MW exclusion limits. Compared to the 6% XL polymer, for some types of carbohydrate and organic acid mixtures, the 8% shows less resolution due to selectivity differences.
Molecular Weight Exclusion Limit: 1200
Minimum Wet Capacity meq/ml: 1.7 - 1.9
Flow Rate Recommendation: 0.4 - 1.2 ml/min
Legal Information
Aminex is a registered trademark of Bio-Rad Laboratories, Inc.
SUPELCOGEL is a trademark of Sigma-Aldrich Co. LLC
全球贸易项目编号
| 货号 | GTIN |
|---|---|
| 59247-U | 04061833519219 |
