328510

4′-Pentyl-4-biphenylcarbonitrile

Name: 4′-Pentyl-4-biphenylcarbonitrile
Brand: ALDRICH

liquid crystal (nematic), 98%

Synonym(s):

4-Cyano-4-pentylbiphenyl, 4-Pentyl-4-cyanobiphenyl, 5CB

Select a Size

Change View

About This Item

Linear Formula:

CH₃(CH₂)₄C₆H₄C₆H₄CN

CAS Number:

40817-08-1

Molecular Weight:

249.35

NACRES:

NA.23

PubChem Substance ID:

24859381

UNSPSC Code:

12352103

EC Number:

255-093-2

MDL number:

MFCD00036350

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

100

assay

98%

form

liquid crystal (nematic)

refractive index

n20/D 1.532 (lit.)

bp

140-150 °C/0.5 mmHg (lit.)

density

1.008 g/mL at 25 °C (lit.)

SMILES string

CCCCCc1ccc(cc1)-c2ccc(cc2)C#N

InChI

1S/C18H19N/c1-2-3-4-5-15-6-10-17(11-7-15)18-12-8-16(14-19)9-13-18/h6-13H,2-5H2,1H3

InChI key

HHPCNRKYVYWYAU-UHFFFAOYSA-N

Description

General description

4′-Pentyl-4-biphenylcarbonitrile (5CB) is a nematic liquid crystal. 5CB undergoes phase transition from crystalline to nematic then to isotropic state at 18^oC and 35^oC respectively. It may be produced by modifying biphenyl.2

Application

Attaching 5CB to an aqueous-liquid crystal interface by redox active surfactant has been investigated.

pictograms

GHS07

signalword

Warning

hcodes

H317

pcodes

P261 - P272 - P280 - P302 + P352 - P333 + P313 - P362 + P364

Hazard Classifications

Skin Sens. 1

Storage Class

10 - Combustible liquids

wgk

WGK 3

ppe

Eyeshields, Faceshields, Gloves, type ABEK (EN14387) respirator filter

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Transition from Spin Dewetting to continuous film in spin coating of Liquid Crystal 5CB.

Palash Dhara et al.

Scientific reports, 8(1), 7169-7169 (2018-05-10)

Spin dewetting refers to spontaneous rupture of the dispensed solution layer during spin coating, resulting in isolated but periodic, regular sized domains of the solute and is pre-dominant when the solute concentration (C n ) is very low. In this

Coupling of the orientations of thermotropic liquid crystals to protein binding events at lipid-decorated interfaces.

Jeffrey M Brake et al.

Langmuir : the ACS journal of surfaces and colloids, 23(16), 8497-8507 (2007-06-28)

We report a study of the interactions of proteins with monolayers of phospholipids (D/L-alpha-dipalmitoyl phosphatidylcholine and L-alpha-dilauroyl phosphatidylcholine) spontaneously assembled at an interface between an aqueous phase and a 20-microm-thick film of a nematic liquid crystal (4'-pentyl-4-cyanobiphenyl). Because the orientation

Preparation of microscopic and planar oil-water interfaces that are decorated with prescribed densities of insoluble amphiphiles.

Maria-Victoria Meli et al.

Journal of the American Chemical Society, 130(13), 4326-4333 (2008-03-14)

Langmuir monolayers (monolayers of insoluble molecules formed at the surface of water), and associated Langmuir-Blodgett/Schaefer monolayers prepared by transfer of Langmuir films to the surfaces of solids, are widely used in studies aimed at understanding the physicochemical properties of biological

View All Related Papers

Global Trade Item Number

SKU	GTIN
328510-1G	04061826717554
