736473

Silver, dispersion

Name: Silver, dispersion
Brand: ALDRICH

nanoparticle, 30-35 wt. % in triethylene glycol monoethyl ether, spec. resistivity ~ 7 μΩ-cm, for printing on ITO films

Synonym(s):

Silverjet DGP-40TE-20C, silver ink

Select a Size

Change View

About This Item

Linear Formula:

CAS Number:

7440-22-4

Molecular Weight:

107.87

NACRES:

NA.23

PubChem Substance ID:

329765114

UNSPSC Code:

12352103

MDL number:

MFCD00003397

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

200

description

Electrodes, surface tension 35 - 40 dyn/cm

form

dispersion, nanoparticle

concentration

30-35 wt. % in triethylene glycol monoethyl ether

refractive index

n20/D 1.333

particle size

≤50 nm

viscosity

10-18 cP

density

1.45 g/mL±0.05 g/mL at 25 °C

storage temp.

2-8°C

SMILES string

[Ag]

InChI

1S/Ag

InChI key

BQCADISMDOOEFD-UHFFFAOYSA-N

Description

General description

Silver is a good conductor and is resistant to oxidation. It is used in printed conductors and printable inks (based on silver nanoparticles). Other large scale applications of nanosilver include metallization of solar cells, thin film electronics, sensors, and catalysts.

Curing Temperature: 180-200 °C

Recommended substrates: ITO film, Ceramic layer

Recommended washing solvent: Polar Solvents: Ethyl Alcohol, IPA etc.

Legal Information

Product of ANP, Inc.

Disclaimer

The product is not intended for use as a biocide under global biocide regulations, including but not limited to US EPA′s Federal Insecticide Fungicide and Rodenticide Act, European Biocidal Products Regulation, Canada’s Pest Management Regulatory Agency, Turkey’s Biocidal Products Regulation, Korea’s Consumer Chemical Products and Biocide Safety Management Act (K-BPR) and others.
