774030

Zirconium(IV) oxide

sputtering target, diam. × thickness 2.00 in. × 0.25 in., 99.95% trace metals basis (excludes 2% HfO2)

Synonym(s):

Zirconia

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Linear Formula:
ZrO2
CAS Number:
1314-23-4
Molecular Weight:
123.22
NACRES:
NA.23
PubChem Substance ID:
329767656
UNSPSC Code:
12352300
EC Number:
215-227-2
MDL number:
MFCD00011310
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

assay

99.95% trace metals basis (excludes 2% HfO2)

form

powder

reaction suitability

core: zirconium

diam. × thickness

2.00 in. × 0.25 in.

mp

2700 °C (lit.)

density

5.89 g/mL at 25 °C (lit.)

SMILES string

O=[Zr]=O

InChI

1S/2O.Zr

InChI key

MCMNRKCIXSYSNV-UHFFFAOYSA-N

Application

Solid Oxide Fuel cells operating at temperatures below 800 C (also known as intermediate temperature solid oxide fuel cell, IT-SOFC) are currently the topic of much research and development owing to the high degradation rates and materials costs incurred for SOFC operating at temperatures above 900 C. Thin films of electrode and electrolyte layers is one of the ways to achieve high performances in IT-SOFC.
Zirconium oxide sputtering target can be used for physical vapor deposition of zirconia thin films for IT-SOFC, thermal barrier coatings, lead zirconium titanate (PZT) films for sensor applications and other zirconium containing films for different applications.

Still not finding the right product?

Explore all of our products under Zirconium(IV) oxide

Storage Class

11 - Combustible Solids

wgk

nwg

flash_point_f

Not applicable

flash_point_c

Not applicable
