916374

Lithium phosphorus sulfide

Name: Lithium phosphorus sulfide
Brand: ALDRICH

LPS, solid electrolyte, powder, battery grade

Synonym(s):

β-LPS, LPS

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):

Li₃PS₄

CAS Number:

82857-67-8

Molecular Weight:

180.06

MDL number:

MFCD01741203

UNSPSC Code:

12352300

NACRES:

NA.23

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Product Name

Lithium phosphorus sulfide (LPS) powder, battery grade

grade

battery grade

Quality Level

100

form

powder

mol wt

M_w 180.06 g/mol

composition

Li₃PS₄

conductivity

0.01-0.1 mS/cm (ionic conductivity, cold-pressed pellet at room temperature)

density

1.83 g/cm³ (lit.)

application(s)

battery manufacturing

Description

Application

Solid electrolytes (SEs) have become a practical option for lithium ion and lithium metal batteries because of their improved safety over commercially available ionic liquids. Solid electrolyte materials are highly conductive and made for advanced solid-state lithium ion battery technologies. These solutions are high purity and battery grade thus making them suitable as standards in LIB research.

pictograms

GHS02,GHS06,GHS05,GHS09

signalword

Danger

Storage Class

4.3 - Hazardous materials which set free flammable gases upon contact with water

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

Hazard Classifications

Acute Tox. 3 Oral - Acute Tox. 4 Inhalation - Aquatic Acute 1 - Eye Dam. 1 - Flam. Sol. 1 - Skin Corr. 1B - Water-react. 1

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number

MKCR0726

MKCM8677

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Inorganic Solid-State Electrolytes for Lithium Batteries: Mechanisms and Properties Governing Ion Conduction.

John Christopher Bachman et al.

Chemical reviews, 116(1), 140-162 (2015-12-30)

This Review is focused on ion-transport mechanisms and fundamental properties of solid-state electrolytes to be used in electrochemical energy-storage systems. Properties of the migrating species significantly affecting diffusion, including the valency and ionic radius, are discussed. The natures of the

Lithium battery chemistries enabled by solid-state electrolytes..

Manthiram A, et al.

Nature Reviews. Materials, 2, 16103 -16103 (2017)
