920134

Graphene, monolayer film

6 in diameter, CVD on silicon wafer, large grain, avg. no. of layers, 1

Synonym(s):

Roll-to-Roll graphene

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):
C
CAS Number:
1034343-98-0
Molecular Weight:
12.01
MDL number:
MFCD00146977
UNSPSC Code:
12141908
NACRES:
NA.23
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

R2R Monolayer large grain CVD graphene on silicon wafer, 6 in diameter, avg. no. of layers, 1

Quality Level

100

description

Growth method: roll-to-roll CVD
Wafer: SiO2 (300nm) Si
Number of layer: Monolayer
Raman intensity 2D/G: ≥1.5

feature

avg. no. of layers 1

sheet resistance

280 Ω/sq ±10%

size

110 μm × 110 μm ± 10%, grain size

surface coverage

surface coverage >98%

transmittance

>97%

semiconductor properties

(mobility>3000 cm2/V·s) (Hall effect measurements)

SMILES string

NC.NC.NC.NC.NC.NC.NC.NC.NC

InChI

1S/9CH5N/c9*1-2/h9*2H2,1H3

InChI key

DXIFQVRACSPGSU-UHFFFAOYSA-N

General description

Roll-to-roll, high-quality, monolayer CVD graphene with large grain size (~110μm^2) on 6 inch silicon wafer.

Application

Our Roll-to-Roll CVD graphene products are true monolayer high quality graphene, fabricated inside a Cleanroom, heavily monitored and QC to assure high reproducibility.
The roll-to-roll process allows continuous, large scale graphene production.

This large grain size graphene product on silicon wafer is ready to use, helps you minimize process time, and increase success rate. This product with low sheet resistance would enable unmatched reproducibility and allow high performance for CVD graphene based FET, CVD graphene based sensors, and heterostructure based micro/nano electronics.

Application examples:
  • Ultrafast Transistor
  • Optical devices
  • Bio/Gas Sensor
  • Transparent Electrode
  • Flexible Display
  • Smart Coating
  • Thermal management

Preparation Note

Avoid direct sun light, avoid high temperature, avoid high humidity, and avoid dust.

Legal Information

Product of LG Electronics, R&D use only

Disclaimer

Be cautious not to drop
Keep away from contamination, heat, dust and flame etc.

Still not finding the right product?

Explore all of our products under R2R Monolayer large grain CVD graphene on silicon wafer

Storage Class

11 - Combustible Solids

wgk

WGK 3
