D7148

3,4-Diaminopyridine

≥98%

Synonym(s):

3,4-DAP, 4,5-Diaminopyridine, Amifampridine, DAP, Pyridine-4,5-diamine

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):
C5H7N3
CAS Number:
54-96-6
Molecular Weight:
109.13
UNSPSC Code:
12352100
NACRES:
NA.22
PubChem Substance ID:
57654120
EC Number:
200-220-9
Beilstein/REAXYS Number:
110232
MDL number:
MFCD00006401
Assay:
≥98%
Form:
powder
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Quality Level

100

assay

≥98%

form

powder

mp

216-218 °C (lit.)

SMILES string

Nc1ccncc1N

InChI

1S/C5H7N3/c6-4-1-2-8-3-5(4)7/h1-3H,7H2,(H2,6,8)

InChI key

OYTKINVCDFNREN-UHFFFAOYSA-N

Gene Information

human ... KCNA1(3736), KCNA10(3744), KCNA2(3737), KCNA3(3738), KCNA4(3739), KCNA5(3741), KCNA6(3742), KCNA7(3743), KCNB1(3745), KCNB2(9312), KCNC1(3746), KCNC2(3747), KCNC3(3748), KCNC4(3749), KCND1(3750), KCND2(3751), KCND3(3752), KCNF1(3754), KCNG1(3755), KCNG2(26251), KCNG3(170850), KCNG4(93107), KCNH1(3756), KCNH2(3757), KCNH3(23416), KCNH4(23415), KCNH5(27133), KCNH6(81033), KCNH7(90134), KCNH8(131096), KCNQ1(3784), KCNQ2(3785), KCNQ3(3786), KCNQ4(9132), KCNQ5(56479), KCNS1(3787), KCNS2(3788), KCNS3(3790), KCNV1(27012), KCNV2(169522)

General description

3,4-Diaminopyridine, also known as Amifampridine, is a heterocyclic compounds commonly used as a building block during the used for synthesis of Imidazo[4,5-c]pyridine and Co(III) Schiff base complexes.

Application

3,4-Diaminopyridine can be used as a heterocyclic building block to prepare:
  • Imidazo[4,5-c]pyridine, an important scaffold used for the preparation of CP-885316.
  • 9-Azajulolidine derivatives, which are used as efficient organocatalysts for acylation and aza-Morita-Baylis-Hillman reaction.
  • 2-Phenylpyrido[3,4-b]pyrazine by condensation reaction with α-methylsulfinylacetophenone in benzene/acetic acid as a solvent.

Still not finding the right product?

Explore all of our products under 3,4-Diaminopyridine

pictograms

Skull and crossbones
GHS06

signalword

Danger

Hazard Classifications

Acute Tox. 2 Inhalation - Acute Tox. 2 Oral - Acute Tox. 3 Dermal - Eye Irrit. 2

Storage Class

6.1A - Combustible acute toxic Cat. 1 and 2 / very toxic hazardous materials

wgk

WGK 3

ppe

Eyeshields, Faceshields, Gloves, type P3 (EN 143) respirator cartridges

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
BCCD6340
BCCB1729
BCBZ9128
BCBX1005
BCBW5044

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Monika Cecilija Žužek et al.
Toxicology letters, 281, 95-101 (2017-09-25)
The effects of natural polymeric alkylpyridinium salt (nPoly-3-APS), a potent acetylcholinesterase inhibitor isolated from the marine sponge Reniera sarai, were studied on isolated mouse phrenic nerve-hemidiaphragm muscle preparations using electrophysiological approaches. nPoly-3-APS inhibited nerve-evoked isometric muscle twitch and tetanic contraction
Raman Tandon et al.
Chemistry (Weinheim an der Bergstrasse, Germany), 19(20), 6435-6442 (2013-03-19)
New heterocyclic derivatives of 9-azajulolidine have been synthesized and characterized with respect to their nucleophilicity and Lewis basicity. The Lewis basicity of these bases as quantified through their theoretically calculated methyl-cation affinities correlate well with the experimentally measured reaction rates
Roger Kalla et al.
Journal of neuro-ophthalmology : the official journal of the North American Neuro-Ophthalmology Society, 31(4), 320-325 (2011-07-08)
Animal experiments have demonstrated that aminopyridines increase Purkinje cell excitability, and in clinical studies, 4-aminopyridine (4-AP) and 3,4-diaminopyridine (3,4-DAP) improved downbeat nystagmus. In this double-blind, prospective, crossover study, the effects of equivalent doses of 4-AP and 3,4-DAP on the slow-phase
